GBantireflex - Antireflex coating for more transmission

GBantireflex can be applicated to enhance the light transmission trough transparent substrates made of plastics. This antireflective coating increases the transmission of UV-rays of a defined spectrum. Due to this the coated substrates are even more effective. The AR coating GBantireflex is especially useful for surfaces of optical lenses, sensors, coverings or similar to enhance the precision of such devices.

• reduces reflection and increases transmission inside a defined spectrum by 3 up to 5 %
• maximum temperature load: 130 °C
• film thickness from 5 up to 10 µm
• scratch-resistant (scratch hardness acording to DIN EN ISO 1518: up to 10 N; pencil hardness according to DIN EN ISA 15184: up to 10H)
• abrasive hardness (cross-cut test according to DIN EN ISO 2409)
• chemical-proof to customary detergents and disinfection methods
• no change in optic or haptical quality of the substrate
• highly transparent
• mechanically flexible

The application process of the antimirobial coating can be matched individually to the geometry and the requirements of the surface.

• certified according to REACH and RoHS
• certified according to ISO 9001:2015; processes comply with IATF 16949
• environmental management conforms to ISO 14001
