GBprotect plastics - UV coating and anti-scratch coating

Being used outdoors, plastic components are exposed to the ultraviolet radiation of the sun, detrimental chemical substances in the atmosphere and mechanical influences. This harmful impacts are causing damages and reducing the lifespan of a product significantly. But even indoors, plastic products are not always safe: regular use damages the surface, which affects functionality and aesthetics. Ultimately, this also affects the value of the product.

GBneuhaus provides a range of innovative nano coatings, including the GBprotect plastics application. It provides protection against these hazardous influences as well as it ensures that high-quality components retain their optical features and maintain their performance. GBprotect plastics creates a barrier that minimizes the permeability for UV-light. Due to this the substrate will be effectively protected against the UV-rays. Furthermore GBprotect plastics prevents damages caused by mechanical influences thanks to the nanoparticles that build a glass-like protective coating with a higher scratch-resistance than the substrate. In this way an effective scratch protection is created.

GBprotect plastics makes plastic parts even more efficient. The lifespan of the product is significantly increased trough which costs and material can be saved. That is good for your customers and in the end good for the environment too.

• protection against UV-radiation and detrimental substances in the atmosphere
• reduction of UV-spectrum (200 – 380 nm) to less than 1%
• combined filter effect in the visible spectrum on request
• combinable with hydrophobic coating GBhydrophobic on request
• maximum temperature load: 200 °C
• film thickness from 5 up to 10 μm
• scratch resistant (scratch hardness according to DIN EN ISO 1518 depending on the substrate up to 20 N, pencil hardness according to ISO 15184 up to 10 H)
• abrasive hardness (cross-cut test according to DIN EN ISO 2409)
• chemical-proof to customary detergents and disinfection methods
• mechanically flexible

• displays
• keyboards
• coverings
• decorative surfaces
• cases
• sensors
• handles
• buttons
• other surfaces made of plastics

The application process of the antimirobial coating can be matched individually to the geometry and the requirements of the surface.

• certified according to REACH and RoHS
• certified according to ISO 9001:2015; processes comply with IATF 16949
• environmental management conforms to ISO 14001
